CHMER HM6050L | MÁY PHAY TỐC ĐỘ CAO - HM SERIES

Mô tả

GANTRY TYPE LINEAR MOTOR DRIVE 5-AXIS MILLING MACHINE

1) New optimized gantry structure design
2) In house Linear Motor Drive
3) Constant Temperature Unit
4) Spindle Temperature Compensation Function
5) 5 Axis CNC Controller
6) Graphite Cutting Unit

Chi tiết

Specification

Model	Unit	HM6050L
Spindle Speed (Max.)	RPM	3000-30000
Spindle Taper	--	HSK E50
Spindle Motor (S1/S6)	KW	15/17
Working Table Size	mm	550x650
T-slot	mm	14x5x100
Max. Load of Table	kg	300
Travel (XxYxZ)	mm	500x620x300
Distance from table to spindle nose	mm	150-450
Work Feed	M/min	1~10
X. Y. Z axis servo motor (Max.)	--	X,Y,Z axis Linear Motor
Outside Dimension (WxDxH)	mm	2600x2600x2470
Net Weight	Kg	3900
