CHMER HM4030L | MÁY PHAY TỐC ĐỘ CAO - HM SERIES

Features
Gantry Structure Design
The best and rigid design by FEA (Finite Element Analysis) to optimize the gantry structure of the high rigidity and heavy loading for the machining stability.
Automatic Tool Changer
Automatic tool magazine with 16 tools for various applications.
Automatic Tool Length Measurement
Measuring the tool automatically and automatic offset of tolerance during machining to ensure the accuracy.
Oil Shroud (for graphite machining) (Opt.)
The self-developed oil shroud to efficiently seal the graphite dust for a better protection for the operator.
Suction Device (for graphite machining) (Opt.)
Efficiently suck off the graphite dust for a better protection for the operator.
New Controler Panel
Ergonomical panel design for more convenient and easier operation
Optional Spindles (Std./Opt.)
Different spec of spindles for customer choise and the customized Z axis design suitable for the chosen spindle to apply on the workpiece.
Disk Oil Skimmer (Opt.)
Efficiently remove the floating oil on coolant surface preventing the coolant from deterioration.
Oil Mist Blast (Opt.)
For more efficient and better metal surface cutting and to reduce the wear of tools.


Specifications
Model	Unit	HM4030L
Spindle speed (Max.)	RPM	8000-30000
Spindle taper	-	HSK E32
Spindle motor (S1/S6)	KW	3/5
Woking Table Size	mm	500x400
T-slot	mm	16x4x100
Max. Load of table	kg	120
Travel (XxYxZ)	mm	400x300x200
Dist. from table surface to spindle nose	mm	150-350
Work feed	M/min	10
Rapid Traverse (X,Y,Z)	M/min	X:36 Y:42
X.Y.Z. axis servo motor	-	X,Y,Z axis Linear Motor
Total power consumption (Max.)	KAV	15
Net Weight	kg	2750



Optional Accessories	●  Standard   ○  Option
Buit in Spindle	HM4030L
HSK E32/30000rpm(Grease) 3~5KW	●
HSK E32/36000rpm(Oilmist) 3~5KW	○
HSK E40/30000rpm(Grease) 10~11.5KW	○
HSK E40/36000rpm(Oilmist) 10~11.5KW	ꟷ
HSK E40/30000rpm(Grease) 10~11.5KW (Vector)	ꟷ
HSK E50/36000rpm(Oilmist) 15~17KW (Vector)	ꟷ
HSK E32/40000rpm(Oilmist) 15KW (Magnet Vector)	○
HSK E40/30000rpm(Grease) 20KW (Magnet Vector)	ꟷ
Hight precision temperature control system	●
chiller for spindle	●
Tool Magazine capacity
ATC Automatic tool changer (16 tools)	●
Automatic tool length measurement	●
Laser control NT	○
System controller
GENTEC M3HN (3 axis network)	●
GENTEC M4HN (4 axis network)	○
GENTEC M5HN (5 axis network)	○
SIEMEN S828D	○
SIEMEN S840D	○
Cutting Process
Cutting air blast	●
Graphite Cutting device	○
Oil mist blast	○
Oil mist Collector	●
Disk oil skimmer	○
Operational Support
MPG hand wheel	●
Ethernet card	●
X, Y, Z axis Linear scale	●
4th, 5th axis synchrinous control	○
Others
Power supply air conditioner	●
3 color machine signal tower light	●
Work lamp	●
Tool kit	●
1GB Dram GENTEC	●
2GB high capacity CFcard GENTEC	●
Tool Holder	○
Tool Collect	○
Pneumatic freezing dryer	○
Automatc voltage regulator	○
Interlligent information Management Center	○
Patented cooling system	○
Visual monitoring device	○
